Description

SKU	VOPC-15 ARM	VOPC-17 ARM	VOPC-19 ARM	VOPC-156 ARM	VOPC-185 ARM	VOPC-215 ARM	VOPC-236 ARM	VOPC-27 ARM	VOPC-32 ARM
Screen Size	15”	17”	19”	15.6”	18.5”	21.5”	23.6”	27”	32”
Resolution	1024×768	1280×1024	1280×1024	1366 x768	1920 x1080	1920 x1080	1920 x1080	1920 x1080	1920 x1080
Viewing Angle	89/89/89/89	85/85/80/80	85/85/80/80	45/45/20/40	89/89/89/89	89/89/89/89	89/89/89/89	89/89/89/89	89/89/89/89
Brightness	350 cd/㎡	250 cd/㎡	250 cd/㎡	220 cd/㎡	250 cd/㎡	250 cd/㎡	250 cd/㎡	250 cd/㎡	250 cd/㎡
Contrast Ratio	1000:1	1000:1	1000:1	500:1	1000:1	3000:1	3000:1	1000:1	1200:1
Touchscreen	Capacitive
Controller	USB interface
Durability	≥ 5M times
Processor Family	ARM, Rockchip
Memory Type	2G, 4G, 8G
Storage Type	32G, 64G, 128G		3588: 64G, 128G, 256G
Ethernet / LAN	1x LAN		2x LAN
Serial / Com	2x RS232 (1x COM option RS485)
USB	2x USB
Video Outputs	1x HDMI
Expansion Slots	1x Mini PCIE
Operating Systems	Android, Linux
Dimension	358.4×286.7×49.5mm	384.1×316.2 x50.7mm	429×356.5×49.2mm	392 x242 x49.5mm	457.2×281.7×49.6mm	533.6×320.9 x51.3mm	572.1×345.6 x51.3mm	657x398x51.5mm	770.7×465.6 x57.2mm
Mounting Hole Size	349.4 x277.2mm	381×312.9mm	425.5×350.5mm	387.2 x237.2mm	453.4×277.5mm	527.9×314.9mm	567.6×341.2mm	651.1×394.2mm	765.6 x460.3mm
Gross Weight	3.70kg	5.60kg	6.20kg	3.70kg	4.10kg	5.70kg	6.00kg	9.20kg	12.50kg
Mounting Options	Embedded, Wall Mount, Desktop Stand
Operating Temperature	-30℃ ~ +70℃
Storage Temperature	-40℃ ~ +80℃
Humidity Rage Non-condensing	5% – 95%
Power	Input Voltage Range 9 – 36V DC Standard Power: Optional 12V AC/DC Adapter: 5A, 60W
