Description
| SKU | VFACEH-17 |
| Screen Size | 17” |
| Resolution | 1280×1024 |
| Viewing Angle | 85/85/80/80 |
| Brightness | 250 cd/㎡ |
| Contrast Ratio | 1000:1 |
| Touchscreen | Capacitive, Resistive |
| Controller | USB interface |
| Durability | Capacitive: ≥ 5M times, Resistive: : ≥ 100,000 times |
| Chipset | H310 (LGA1151), H610 (LGA1700) |
| Memory Type | 2x DDR4 4G, 8G, 16G, 32G |
| Storage Type | 1x M.2 Slot, support M.2 2260/2280 |
| Ethernet / LAN | 2x RTL8111 |
| Serial / Com | 2x RS232 (COM2 option RS485) |
| USB | Front 1x USB, Rear 4x USB |
| Video Outputs | 1x HDMI, 1x VGA |
| Expansion Slots | 1xMini-PCIE WiFi, 1x Mini PCIE WiFi & Bluetooth or 4G LTE |
| Operating Systems | Windows, Linux |
| Dimension | 397.8x354x71.4mm |
| Mounting Hole Size | 384x343mm |
| Gross Weight | 6.00kg |
| Mounting Options | Embedded, Wall Mount, Desktop Stand |
| Operating Temperature | -30℃ ~ +70℃ |
| Storage Temperature | -40℃ ~ +80℃ |
| Humidity Rage
Non-condensing |
5% – 95% |
| Power | Input Voltage Range 9 – 36V DC
Standard Power: Optional 12V AC/DC Adapter: 5A, 60W |
